Blacktip Tech Tube Kit

Blacktip Tech Tube Kit

Dive Xtras Blacktip Scooter (Exploration)

$2,399.00

BlackTip Exploration Specifications

Weight 37lbs
Length 37in
Depth Rating 260ft (80m)
Continuous Max Speed 210ft/min
Boost Mode Max Speed 238ft/min
Boost Mode Max Runtime 7min
Boost Mode Max Thrust 57lbs
Availability: In stock
SKU
DPV0004

Blacktip Scooters are Currently on Backorder!

You will be added to the queue as soon as you order, current wait time is ~3 weeks.

BlackTip Exploration Specifications

Weight 37lbs
Length 37in
Depth Rating 260ft (80m)
Continuous Max Speed 210ft/min
Boost Mode Max Speed 238ft/min
Boost Mode Max Runtime 7min
Boost Mode Max Thrust 57lbs

Scooter Battery Info

Runtime and range will vary, depending on your choice of batteries. See below for specs on different battery options. (Batteries and charger not included with purchase of scooter)

BlackTip w/ 9Ah Battery BlackTip w/ 12Ah Battery
Runtime at Cruise Speed
(150 ft/min; 45 m/min)
185 minutes 250 minutes
Range at Cruise Speed
(150 ft/min; 45 m/min)
5.3 miles (8.5km) 7.1 miles (11.4km)

Compatible with 9Ah or 12Ah, 20v (USA only) or 18v batteries that fit the DCB interface.

Does NOT include batteries or charger



BlackTip Exploration Performance Charts



This graph shows the performance, range and runtime for the Pegasus Thruster

The graph shows the performance, range and runtime for the Bonex Aquaprop L

This graph shows the performance, range and runtime for the Yamaha 500Li

The graph shows the performance, range and runtime for the Scubajet Pro 200Wh and 400Wh

The graph shows the performance, range and runtime for the Suex VR






User Guide



Programmable Drive Firmware



Product Diagrams






Features






Safe Start

Activating the BlackTip outside of water will trigger a new feature known as ‘safe start’. The BlackTip  propeller will start in a low-power, slow-turning mode if it detects it is not in water. This helps to prevent unintended damage to your scooter or equipment while not actively diving. When the propeller detects water resistance, it will automatically switch to normal operating mode.

Batteries

The BlackTip is powered by a pair of commonly-found power tool batteries installed directly into the body. This makes the scooter easy to charge and even easier to extend the length of your dive by swapping out batteries on the fly. The BlackTip accepts 20v (USA only) or 18v DCB-format power tool batteries. These can be purchased at retailers worldwide or online via Amazon or other seller.

These batteries are generally travel friendly, as the larger capacity batteries have a shipping/travel clip that separates the battery unit into smaller cells to keep them under TSA/IATA limits.

LED Display

The BlackTip features a built-in LED display screen. The screen displays:

  • Current speed setting.
  • Battery level.
  • Battery errors from battery depletion or voltage inconsistency.



Travel

Your BlackTip can be taken on all commercial flights. By utilizing removable and compact power tool batteries, the BlackTip keeps within the TSA/IATA air travel limits on lithium batteries. While all three models share this feature, the added size and weight of the Tech and Exploration scooters make them less ideal for flying. For the jet-setting diver, the BlackTip Travel’s compact size combined with its weight of only 24lbs make it our most travel-friendly option!

Trigger & Speed

During normal operation in water, the BlackTip features eight speed modes. To activate the scooter, press the thumb trigger twice. The BlackTip will briefly engage ‘safe start’ mode to detect whether it is in water, then will switch to normal operation mode and start in speed 3 (known as ‘cruise speed’). Once your BlackTip is running, pressing the thumb trigger twice will accelerate the scooter by one speed, and pressing the trigger once will slow the scooter down by one speed. If you are out of water, the BlackTip will only operate in ‘safe start’ mode.

Silent Operation

Dive Xtras is constantly refining and improving our products. The BlackTip now features new drive firmware, with silent operation! Incredibly quiet and more efficient than ever! The following video shows a comparison of the original BlackTip vs the new silent version.

Programmable Drive

Your BlackTip’s drive is fully programmable. Using a windows PC and the free software you can change settings and update firmware. Settings you can change include:

  • Number Of Gears
  • Speed or Each Gear
  • Acceleration Rate

Saltwater / Freshwater Trim Weight Plate

The BlackTip Exploration also includes a removable weighted plate to balance out your scooter when diving in saltwater. It can be easily removed to adapt to freshwater, making balancing your BlackTip a breeze!

Universal Carry Handle

Your scooter is designed to carry you with ease underwater, but what about when you’re on dry ground? This Universal Carry Handle makes all of that easier by giving you a convenient carrying handle to simply and easily show your scooter how we landlubbers do it while on two feet! (Included with all BlackTip Tech and Exploration models)


Installing Your Saltwater Weight Plate


To install, adjust, or remove your scooter’s saltwater weight plate, loosen and remove the two thumb screws holding it in place inside the body tube. After adjusting your weight plate’s positioning, simply align the grooves of the weight plate with the mounting holes and tighten the screws back into place to finish the adjustment!
